Ortofon 2M Mono
Ortofon OM 5 E
Ortofon 2M Mono Verso
True mono with Nude Spherical diamiond
Output voltage at 1000 Hz, 5cm/sec. |
4 mV |
Channel balance at 1 kHz |
- |
Channel separation at 1 kHz |
- |
Channel separation at 15 kHz |
- |
Frequency range at - 3dB |
20-22.000 Hz |
Frequency response |
20-20.000 Hz + 3 / - 1 dB |
Tracking ability at 315Hz at recommended tracking force |
70 µm |
Compliance, dynamic, lateral |
18 µm/mN |
Stylus type |
Nude Spherical |
Stylus tip radius |
R18 µm |
Tracking force range |
1,6-2,0g (16-20 mN) |
Tracking force, recommended |
1,8 g (18 mN) |
Tracking angle |
20° |
Internal impedance, DC resistance |
700 Ohm |
Internal inductance |
350 mH |
Recommended load resistance |
47 kOhm |
Recommended load capacitance |
150-300 pF |
Cartridge colour, body/stylus |
Black/White |
Cartridge weight without screws |
7,2 g |
Mer information:
SKU |
2M Mono Verso |
Märke |
Ortofon |
Weight |
0.000000 |
Färg |
Vit |
