Nu-Vista PAS - Specifications
Amplifier
- High output power, greater than 300W into 8 ohms, 500W into 4 ohms, 1000W peaks into 2 ohms
- Output Voltage: 49 Volts RMS
- Output Current: 130 Amps peak to peak
- Damping factor: 200
- Output devices: 5 pairs per channel
- Gain: 16x (23.5 dB)
- THD+N: < 0.003 % typical, 20Hz to 20 kHz
- Signal / noise ratio: >108dB ‘A’-weighted
- Channel separation: >96dB
- Input impedance: 100 k Ohms
- Input sensitivity for full output: 3 Volts RMS
- Frequency response: + 0, –1dB, 5Hz to 50 kHz
In & Output
- 4 fully independent inputs: 2x RCA & 2x XLR
- 2 loop through outputs: 1x RCA & 1x XLR
- Speaker outputs: 2 pairs 4mm banana plug/binding posts
- Trigger input and output: 3.5mm mono jack socket
- Trigger level ±5V to ±12V
General Information
- Weight PAS: 27kg net (35kg)
- Weight PAS PSU: 40kg net (50kg)
- Dimensions PAS (WxHxD):
483 x 187,5 x 475 (494 with connectors)
- Dimensions PAS PSU (WxHxD):
483 x 187,5 x 475 (478 with connectors)
- Mains voltages: 115/230VAC 50/60Hz (factory
pre-set); 100VAC 50/60Hz (alternative)
- Consumption <0.5W in standby mode;
130W on and idle; 1060W maximum
