Norstone Pro 19" golvrackskåp 12u

The NorStone 12U - 19" Rack is a robust and functional storage solution designed to accommodate up to 12 units of 19" equipment. This rack is ideal for professional environments where organization and equipment ventilation are essential. It features integrated ventilation grilles on the top, including two fans for optimal temperature management. The removable side panels facilitate installation and cabling, while the perforated square holes allow for easy use with clip-in cage nuts. The tempered glass door, equipped with a key lock and a butterfly handle, provides both security and aesthetics. Additionally, the rack is mounted on 80 mm casters and height-adjustable feet for enhanced mobility and stability.

Capacity & Dimensions

Storage Capacity: 12U
Maximum Usable Depth: 540 mm
Dimensions with Casters (W × H × D): 600 × 720 × 600 mm
Dimensions without Casters (W × H × D): 600 × 640 × 600 mm
Net Weight: 30.8 kg
Maximum Weight per Shelf: 30 kg

Design & Construction

Material: Metal
Color: Satin Black
Integrated Fans: 2
Included Fixed Shelf: 1
Casters: 4 × 80 mm Casters
Height-Adjustable Feet: 4

Door

Type: Tempered Glass Door
Lock: Key Lock with Butterfly Handle
Reversible: Yes

Packaging

Delivered flat-packed with screws, assembly instructions, and required tools
Number of Packages: 3
Carton 1: 650 × 620 × 250 mm — 10.2 kg
Carton 2: 655 × 365 × 90 mm — 9 kg
Carton 3: 655 × 645 × 115 mm — 14.6 kg
Total Gross Weight: 33.8 kg

Compatible Accessories

Ventilation

Fan Tray – 2 Fans
Fan Tray with Thermostat – 2 Fans

Shelves

Fixed Shelf for Rack
Sliding Shelf for Rack

Connection Panels & Cable Management

24-Port RJ45 CAT6 Patch Panel
Cable Management Brush Panel
1U Cable Organizer Panel

Power Distribution

10-Outlet SCHUKO Power Strip
Power Strip with Switch (8 SCHUKO Outlets)

Blanking Panels

Blanking Panels (1U, 2U, 3U, 4U)

Ventilation Panels

Ventilation Panels (1U, 2U, 3U, 4U)

The 12U Rack is an ideal solution for professionals seeking a secure, well-ventilated, and modular installation for 19-inch equipment.

Documents

Technical Data Sheet

SKU	NORPRO1001
Märke	Norstone
