Marantz Cinema 30

Power Amplifier

Multichannel Surround Technologies

Inputs Outputs

Composite In / Out2 / 0
Component In / Out1 / 0
HDMI In / Out7 / 3
Multi-Room Video Out via HDMI0 / 0
Analog In / Fixed Level Out3 in / 0 out
Phono (MM) InYes
Digital In: Optical / Coaxial2 / 2
Multi-Room Out: analog / digital2 / 0
Multichannel Preamp Out7.2
Subwoofer Out4 (independent)
7.1 multichannel inputNo
Number of Speaker Terminals13
Speaker A / Bassignable
Multi-Room Speaker Terminalassignable
Front InputsUSB-A
USB AudioYes / No / No
FM Tuner with RDSYes
DAB+ TunerNo
Multi-Room Video Out: Video / HDMI7/3
analog In/out6 / 0
Multichannel Pre OutYes (13.4)
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USBNo / No / No / No / Yes

HDMI

Total HDMI Inputs / No. Support 8K6 / 3
HDCP2.3 supportYes
HDMI Outputs: Main / Zone2 / 1
Analog to HDMI Video ConversionNo
HDMI Upscaling1080P/4K to 8K
Max resolution @ framerate
Audio Return ChannelARC, eARC
Video Dynamic RangeHDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gamingYes
Variable Refresh Rate / Quick Frame TransportYes / Yes / No
HDMI Pass-Through in Standby ModeYes
CECYes
DSD Audio over HDMINo
Auto LipSyncYes
HDMI Inputs: Back / Front7 / -
Video Conversion Analog -> HDMIYes
HDMI to HDMI Scaling1080P/4K to 8K
HDMI 2.1: 8K/60Hz AB / 4K/120Hz ABYes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-through In/Out7 / 2 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARCYes / Yes / Yes / Yes
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDRYes / Yes / Yes / Yes / Yes
Variable Refresh Rate / Quick Flame Transport / Quick Media SwitchingYes / Yes / No
8K signal pass-through / scaling / GUI overlayo / o / o
4K Signal Pass-Through / Scaling / GUI Overlayo / o / o
DSD Audio CapabilityYes

Performance Technologies

Acoustic Room Correction

Music File Support

Streaming Services

Network Connectivity

Smart Home Integration and Control

Voice Assistant CompatibilityAlexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android)Marantz AVR App
HEOS Multi-Room IntegratedYes
HEOS Link Compatibility: IR/ IPYes /Yes
Multi-Room zones2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / PreoutYes / Yes
Zone HDMI Output from HDMI SourceYes
Control ConnectivityIP Control / RS232 Control / Web Control / App Control
IR Flasher InYes
Marantz Remote BusYes
DC Trigger Output3
HDMI DiagnosticsYes

Others

General

Available ColorsBlack/Silver-Gold
Metal Front PanelYes
System Remote ControlRC-051SR
Power Consumption in W780
Power Consumption No-Sound (ECO on/off) in W65 W / 110 W
Standby Consumption in W0.2
CEC Standby Consumption in W0.5
Network Standby Consumption in WLess than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mm442 x 457 x 189
442 x 457 x 257
442 x 447 x 189
Weight in kg19.4
What's in the boxMain unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, cardboard microphone stand, 2 External Detachable Antennas, AC cord
Weight in lbs.42.8
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mm17.4 x 18.0 x 7.5
(17.4 x 18.0 x 10.2)
【17.4 x 17.6 x 7.5】
Pre-Programmed / Learnable / LCD DisplayYes / Yes / Yes
