M6x 250.4/2 - Specifications

Output

• 2-channel Bridged Power (all channels driven): 250W/4 ohms, 180W/8 Ohm (400W Peak/2 Ohm)
• 4-channel Power (all channels driven): 175W/4 ohms, 90W/8 Ohm (250W Peak/2 Ohm)
• THD+N: 0,003% at 100W power output
• Frequency Response: 20Hz - 20kHz for 0,5dB
• SNR: 105dB at 1kHz at 200W power output

Connections

• 4x line level RCA input
• 4x line level balanced XLR input
• 4x line level RCA through output
• 4x pair speaker terminals
• 1x Trigger input & output

Input Sensitivity

• 700mV at RCA input, 1,4V at XLR input

General Information

• Dimensions (WxHxD): 435 x 110 x 435mm
• Main voltages: 230V/115V Internally set or 100V optional AC 50/60Hz
• Max. Consumption: 1000W, <0.5W in standby
• Weight: 21,5kg (ca. 24kg incl. shipping carton)
