KEF The Reference Ci3160REF-THX
THX® Certified Ultra in-wall Architectural Speaker
Ci3160REF-THX# använder REFERENCE-teknologier för att möta standarderna i den legendariska REFERENCE-serien, såväl som KEF:s Extreme Theater och THX® Certified Ultra. Den levereras till och med med ett REFERENS Build Certificate signerat av hantverkaren som gjorde det.
*Denna produkt kan ta 12-14 veckor för leverans.
I lager
- SKU
- KEF The Reference Ci3160REF-THX
94 990,00 kr
Köp nu, betala med
Läs mer
Betala 7 961,00 kr/månad i 12 månader (0% ränta).
Uppläggningsavgift: 295,00 kr
Administrationsavgift per månad: 45,00 kr
För 12 månader blir det totalt 95 826,00 kr.
Ci3160REF-THX
Ci3160REF-THX takes in-wall performance to new heights. Whether used as a two-channel pair or as part of a complete home theatre system in any combination of KEF Architectural and traditional speakers, Ci3160REF-THX delivers countless possibilities for REFERENCE performance.
Flawless Sound
Ci3160REF-THX utilises the latest Uni-Q point source driver array. A 25mm vented aluminium dome tweeter sits at the exact acoustic centre of a 125mm mid-range driver. Together they act as a single source, flooding the listening space evenly with flawlessly natural sound.
Brilliant Bass
Ci3160REF-THX’s bespoke 160mm bass driver is optimised for in-wall performance. With a massive vented magnet assembly and a large aluminium wire voice coil driving an exceptionally light, stiff and strong alloy cone, the dynamics and power handling are exceptional.
Auditioning perfection
Ci3160REF-THX’s crossover combines the science of computer-modelling with the rigours of exhaustive auditioning and refinement of each high-grade component. Only components with the lowest distortion and the smoothest response make the grade for this exceptional loudspeaker. #For optimised performance, THX recommends using the Ci3160REF-THX without grille or fabric grille.
The Details
SPECIFICATIONS
Nominal Impedance
4 Ohms
Sensitivity
90dB (2.83V/ 1m)
Frequency Response (±6DB)
Open-backed
Open-backed
40Hz - 28kHz (±6dB)
Frequency Range (-10DB)
32Hz-30kHz
Nominal Coverage (Degrees)
115
Crossover Frequencies
350Hz, 2.7kHz
Drive Units
LF: 2 x 160mm (6.5 in.)
MF: 125mm (5.25 in.) Uni-Q
HF: 25mm (1 in.)
MF: 125mm (5.25 in.) Uni-Q
HF: 25mm (1 in.)
Recommended Amplifier Power
40 - 350W
Recommended High-pass Filter (HZ)
40Hz
Product External Dimension (H X W X D)
680 x 230 x 105.7 mm (26.77 x 9.06 x 4.16 in.)
Cut-out Dimensions (H X W)
660 x 209 mm (25.98 x 8.23 in.)
Mounting Thickness (Maximum)
40mm
Mounting Thickness (Minimum)
6mm
Mounting Depth from Surface
99mm (3.9 in.)
Optional Rough In Frame
RIF3160L
Ideal Rear Volume (L)
60
Minimum Rear Volume (L)
30
Max SPL (dB)
110
Certification
THX Ultra
Safety and Regulatory Compliance
NA
Net Weight
13.4Kg (29.54Ibs.)
Unit Measurement
Piece
| SKU | KEF The Reference Ci3160REF-THX |
|---|---|
| Märke | KEF |
| Weight | 1.000000 |
