Devialet Phantom I 103dB

TECHNICAL DESCRIPTION

SOUND PRESSURE LEVEL

101 dB SPL at 1 meter

AMPLIFICATION POWER

1200 W peak

AMPLIFICATION PERFORMANCES(*TOTAL HARMONIC DISTORTION + NOISE)

THD+N* : 0.0005% | Saturation : 0 | Background Noise 0 dB SPL at 50 cm (-15,5 dB SPL at 3m)

ACOUSTICAL PERFORMANCE

Bandwith: 16Hz to 25kHz (@-6dB) Accuracy in frequency response : ± 2dB from 20Hz to 20kHz

TECHNOLOGIES

ADH2®; SAM®; HBI®; EVO®; ACE®

LOUDSPEAKERS

Aluminum Tweeter driver
Aluminum Medium driver
Aluminum Bass drivers

DIGITAL TO ANALOG CONVERTER

Devialet DAC embedded in ADH2® intelligence

24bits/192kHz

THD: -112dB

PROCESSOR

ARM Cortex-A9 MPCore 800MHz dual-core processor | hard IP | FPGA in a unique System-On-Chip (SoC) Cyclone V 512MB DDR3 memory

MATERIALS

Composite body | Internal skin: glass fiber filled polycabonate | External skin: ABS | Aluminum central core

COLOR AND FINISH

Body: white RAL 9016 | Polished stainless steel sides | White RAL 9016 dome drivers

DIMENSION

Width: 253 mm | Height: 255 mm | Depth : 343 mm

WEIGHT

11,4 kg

POWER SUPPLY

IEC 90-240 V~50/60Hz

SYNCHRONISATION

PHANTOM synchronisation via Wi-Fi, Ethernet or PLC.

APPS

Spark (Windows 7+, Mac OSX 10.12+, iOS 10+, Android 5+), Remote (iOS)

AVAILABLE SERVICES VIA WI-FI USING DEVIALET SPARK APP

Local Music, Deezer, Spotify, Qobuz, Tidal, Web Radios, Live on Phantom

AUDIO FORMATS

HE-AAC (V1), AAC (16 to 320 kbit/s), WMA (16 bit), MP3 (16 to 320 kbit/s), MP3 VBR, Apple Lossless, AIFF and WAV, FLAC, OGG, VORBIS

CONNECTIVITY

Airplay

UPnP Renderer

Bluetooth : A2D and AVRCP profiles, aptX, AAC, SBC audio codecs

Spotify Connect

Proprietary Network Wi-Fi Dual-band (a/b/g/n 2.4 GHz & 5 GHz)

Ethernet RJ-45 10/100/1000 Mbps (Gigabit)

CPL Homeplug AV2

Toslink optical input (TV, CD player, Blu-Ray, video games console...)

SKU	Devialet Phantom I 103dB-1
Märke	Devialet
Weight	2.000000
Garanti	1år

Alternativ
