Specifications
| Frequency Response | 20-200Hz ±3dB |
| Max Acoustic Output | 130dB @ 30Hz| 122dB @ 20Hz| 112dB @ 15Hz 1/8 space| 1M (2 enclosures side-by-side per THX Ultra2) |
| Nominal Impedance | 8 ohms |
| Enclosure Type | Bass-reflex via front-firing slot port |
| Amplifier Type | Use only with KA-1000-THX |
| Amplifier Power | See KA-1000-THX specifications |
| Woofer | 12" (30.5cm) front firing| Cerametallic™ cone| cast aluminum frame driver with a 240oz ceramic magnet structure |
| Dimensions | 20.25" (51.4cm) H x 17.75" (45.1cm) W x 17.75" (45.1cm) D (w/grille) |
| Weight | 80 lbs. (36kg) |
| Speaker Enclosure | Medium density fiberboard construction(MDF) |
| Finish | Galaxy Black cabinet with Black anodized aluminum fascia |
