Specifications
| Frequency Range | 46Hz - 23kHz +/- 3dB |
| High Frequency Driver | 1" (2.54cm) Titanium Dome Tweeter mated to a composite coated Hybrid Cross Section Tractrix® Horn |
| Low Frequency Driver | Dual 5.25" (13.34cm) Cerametallic Woofers |
| Sensitivity | 94 dB @ 2.83V / 1m |
| Coverage Angle | 90° x 90° |
| Power Handling | 75W RMS / 300W Peak |
| Impedance | 8 Ohm Compatible |
| Enclosure Type | ABS/Infinite Baffle |
| Finish | Black Baffle/Frame| White Paintable Grille |
| Product Dimensions | 7.5” W x 17.4” H x 3.8” D (19.1cm H x 44.2cm W x 9.6cm D) |
| Mounting Depth | 3.78” (9.35cm) |
| Cutout Dimensions | 16.5” H X 6.5” W (41.9cm H X 16.5cm W) |
| Product Weight | 6.5lbs (2.95kg) |
| Included | Grille| Paint Shield |
| Installation Kit | IK-502-W (Sold Separately) |
| Built From | 2017 |
