Linn fjärrkontroll REM/022

Basic Functions

1. SLEEP - Will put the unit into / out of Sleep mode.
2. NUMERICAL KEYS - Numerical input.
3. ★ - Reserved for future use
4. SHUFFLE - press to toggle Shuffle state

   - Press and hold for 2 seconds for HELP information (Davaar 69 onwards)

   --e.g. IP address, MAC etc.

5. NAVIGATION / SELECT - Up / down / left /right / enter keys for playlist navigation.

   e.g.

   • Left and right keys

   • Seek through tracks during playback
   • go into and escape options...

   • Up and down keys

   • Scroll though Radio presets/playlist tracks
   • Scroll through sources...

6. PINS - For switching between PINS, these buttons will work with any Linn DS/DSM running Davaar 64 or higher.
7. TRANSPORT CONTROLS - Play, pause, skip forward, skip back.

   • Press and hold pause will stop playback

8. MUTE - To mute / unmute volume.
9. VOLUME + , - - Volume + , -.
10. SOURCE + , - - Source + , -.
11. INFORMATION - changes information displayed on the DSM

    front panel

• Press and release - toggles different display modes e.g. track

number, bit rate etc

• Press and hold - scrolls the current track playing
